FEATURES
- Used for driving spikes in used or seasoned ties.
- Internal oiler.
SCHEMATIC
KT-SD60 Spike Driver Schematic: Click Here for PDF
SPECIFICATIONS
| Net Weight | 64 lbs (29 kg) |
| Length | 24.5 in (622 mm) |
| Bore | 2.25 in (57 mm) |
| Stroke | 4.0937 in (104 mm) |
| Blows Per Minute | 1400 |
| Air Inlet (NPT) | 3/4 in (19 mm) |
| Air Consumption* | 59 cfm (1.7 m3/m) |
| *estimated |
*For optimum performance, do not operate tool above 90 PSI (6 bar) working pressure.
WARNING: Always disconnect the air supply before changing chisels or dismantling the tool for service or repair. For maximum safety, we advise the installation of a shut-off valve at the end of the air line.
Do NOT exceed 100 PSI (7BAR) working pressure.
CONDITION
- Brand new
